*Plus destination charge: $995
| Hypermotard V2 | Hypermotard V2 SP | |
|---|---|---|
| Engine | ||
| Type | Superquadro Mono, single-cylinder, 4 valves per cylinder, Desmodromic timing, 2-balance countershafts, liquid cooled | Ducati V2 engine: 90° V2, 4 valves per cylinder, intake variable valves timing system, liquid cooled |
| Displacement | 659 cc | 54.3 cu in (890 cc) |
| Bore x Stroke | 116 x 62.4 mm | 3.8 in x 2.4 in ( 96 mm x 61.5 mm) |
| Compression Ratio | 13.1:1 | 13.1:1 |
| Power | 77.5 hp (57 kW) @ 9,750 rpm | 120,4 hp (88.5 kW) @ 10,750 rpm |
| Torque | 46.5 lb-ft (63 Nm) @ 8,000 rpm | 69 lb ft (94 Nm, 9.6 kgm) @ 8,250 rpm |
| Fuel Injection | Electronic fuel injection system, Øe 62 mm throttle body with full Ride by Wire system | Electronic fuel injection system. One injector per cylinder. Full ride-by-wire. |
| Exhaust | 1-2 exhaust system, double aluminum mufflers, catalytic converter and lambda probe | 2-1-2 system |
| Transmission | ||
| Gearbox | 6 speed with Ducati Quick Shift Up/Down | 6 speed with Ducati Quick Shift up/down 2.0 |
| Primary drive | Straight cut gears; Ratio 1.968:1 | Straight cut gears; Ratio 1.84:1 |
| Ratio | 1=36/13 2=35/17 3=32/20 4=29/22 5=24/21 6=26/25 | 1=38/14 2=34/17 3=32/20 4=29/22 5=24/21 6=26/25 |
| Final drive | Chain 520; Front sprocket 15; Rear sprocket 42 | Chain 520; front sprocket 15; rear sprocket 42 |
| Clutch | Slipper and self-servo wet multiplate clutch, hydraulic control | Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder |
| Chassis | ||
| Frame | Tubular steel Trellis frame | Monocoque Aluminium |
| Front suspension | Ø 45 mm Marzocchi fully adjustable aluminum fork | Ø48 fully adjustable Öhlins fork |
| Front Wheel | Y shaped 5-spoke light alloy 3.5" x 17" | Forged aluminium 3,5"x17" |
| Front Tire | Pirelli Diablo Rosso IV, 120/70 ZR17 | Pirelli Diablo Rosso IV Corsa, 120/70 ZR17 |
| Rear suspension | Progressive linkage with Sachs fully adjustable monoshock. Aluminum double-sided swingarm | Fully adjustable Öhlins shock absorber, Aluminum double-sided swingarm |
| Rear Wheel | Y shaped 5-spoke light alloy 5.0" x 17" | Forged aluminium 5,5" x 17" |
| Rear Tire | Pirelli Diablo Rosso IV, 160/60 ZR17 | Pirelli Diablo Rosso IV Corsa, 190/55 ZR17 |
| Wheel Travel (Front/Rear) | 8.5 in (215 mm) - 9.4 in (240 mm) | 6.7 in / 6.3 in (170 mm / 160 mm) |
| Front Brake | Ø 330 mm aluminum flange disc, Brembo M4.32 caliper, radial pump with adjustable lever, with Bosch Cornering ABS | 2 x Ø 320 mm semi-floating discs, radially mounted Brembo Monobloc M50 4-piston callipers, radial master cylinder. Cornering ABS. |
| Rear Brake | Ø 245 mm disc, single piston floating caliper, with Bosch Cornering ABS | Ø245 mm disc, 2-piston caliper. Cornering ABS |
| Instrumentation | 3.8" LCD display with Improved Black Nematic (IBN) technology | Digital dashboard with 5'' full-color TFT display, 800 x 480 px resolution; 16:9 ratio |
| Dimensions and Weights | ||
| Wet weight no fuel | 333 lb (151 kg) | 390 lb (177 kg) |
| Seat Height | 35.6 in (904 mm)
35.0 in (889 mm) with low seat accessory 33.4 in (849 mm) with low seat + low suspension kit accessory |
880 mm (34,6 in)
865 mm (34,1 in) with low seat accessory |
| Wheelbase | 56.8 in (1,443 mm) | 59.6 in (1,514 mm) |
| Rake | 26.1° | 26° |
| Trail | 4.2 in (108 mm) | 4.3 in (110 mm) |
| Fuel Tank Capacity | 3 US gallons (12 l) | 3.3 US gal (12.5 l) |
| Number of Seats | 2 | 2 |
| Equipment | ||
| Safety Equipment | Riding Modes, Bosch Cornering ABS, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Ducati Brake Light (DBL)* | Riding Modes, Power Modes, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Engine Brake Control (EBC), Bosch Cornering ABS |
| Standard Equipment | Ducati Quick Shift (DQS) up/down, Power Modes, Ducati Power Launch (DPL), Full LED lighting system, Daytime Running Lights (DRL)*, Tapered aluminum handlebars, Lithium-ion battery, Termignoni type approved silencers, Nera livery | Ducati Quick Shift (DQS) up/down 2.0, Öhlins suspension, Lithium-ion battery, Quick adjustment buttons, Sachs steering damper, Forged aluminum wheels, Coming Home, Ducati Power Launch (DPL), TFT colour display, Full LED lighting system, Daytime Running Light (DRL)*, Self cancelling turn indicators, Lap Timer, Pit Limiter, Carbon fiber front mudguard |
| Provided Equipment | Passenger footpegs | Passenger footpegs |
| Ready for | Anti-theft system, Heated grips, Ducati Multimedia System (DMS). | Anti-Theft, Cruise control, Ducati Multimedia System (DMS), Lap Timer Pro, Heated grips, Turn-by-Turn navigation system, USB port |
| Warranty | ||
| Warranty | 24 months unlimited mileage | 24 months, unlimited mileage |
| Annual Service | 12 months | 12 months |
| Oil Service | 9,000 miles (15,000 km) / 24 months | 9,000 mi (15,000 km) / 24 months |
| Valve Clearance Check | 18,000 miles (30,000 km) | 28,000 mi (45,000 km) |
| Emissions and Consumption | ||
| Notes | *Please check with your dealer product availability
Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information |
*Please check with your dealer product availability
Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information. |
| Notes | ||
| Notes | *Please check with your dealer product availability
Bike specifications and equipment may vary from market to market. Please refer to your local dealer for further information. |
|
