Multistrada 1100 S (2009)

Motor
Type
L-Twin cylinder, 2 valves per cylinder Desmodromic, air cooled
Cilinderinhoud
1078cc
Boring X Slag
98 x 71.5mm
Compressieverhouding
10.5:1
Vermogen
86hp - 63kW @ 7750rpm
Koppel
69lb-ft 9.6kgm @ 4750rpm
Brandstofinjectie
Marelli electronic fuel injection, 45mm throttle body
Uitlaat
Single steel muffler and pre-silencer with catalytic converter and lambda probe
Transmissie
Versnellingsbak
6 speed
Primaire Aandrijving
Straight cut gears, ratio 1.84:1
Verhouding
1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28
Eindaandrijving
Chain, Front sprocket 15, Rear sprocket 42
Koppeling
Wet multiplate with hydraulic control
Chassis
Frame
Tubular steel trellis frame
Voorvering
Öhlins 43mm fully adjustable upside-down fork with TiN
Voorband
6-spoke in light alloy 3.50 x 17
Voorwiel
120/70 ZR17
Achtervering
Progressive linkage with fully adjustable Öhlins monoshock; hydraulic remote pre-load control. Aluminium single-sided swingarm
Achterwiel
5-spoke light alloy 5.50 x 17
Achterband
180/55 ZR17
wheel-travel-front
165mm / 6.5in
wheel-travel-rear
141mm / 5.6in
Voorrem
2 x 320mm semi-floating discs, 4-piston, 2-pad caliper
Achterrem
245mm disc, 2-piston caliper
Instrumentenpaneel
Speedometer, rev counter, clock, scheduled maintenance warning, warning light for low oil pressure, fuel level, oil temperature, fuel reserve, trip fuel, neutral, turn signals, average speed, average fuel consumption, remaining fuel metre, fuel injection.
Afmetingen en gewichten
Drooggewicht
196kg / 432lb
Zithoogte
850mm / 33.5in
Wielbasis
1462mm / 57.6in
Balhoofdhoek
24°
Inhoud brandstoftank
20l (of which 6.5l reserve) / 5.3US gal (of which 1.7US gal reserve)
Aantal zitplaatsen
Dual seat
Garantie en onderhoud
Garantie
2 years unlimited mileage
Emissies en verbruik
Standaard
Euro 3
