Engine

Testastretta, L-Twin cylinder, 4 valve per cylinder, Mono Spark, Desmodromic, liquid cooled

Testastretta, L-Twin cylinder, 4 valve per cylinder, Mono Spark, Desmodromic, liquid cooled

Displacement

937 cc

937 cc

Bore X stroke

94 x 67,5 mm

94 x 67,5 mm

Compression ratio

12,6:1

12,6:1

Power

83 kW (113 CV) @ 9.000 giri/min

83 kW (113 CV) @ 9.000 giri/min

Torque

96 Nm (71.0 lb-ft) @ 7,750 rpm

96 Nm (71.0 lb-ft) @ 7,750 rpm

Fuel injection

Bosch electronic fuel injection system, cylindrical throttle bodies with Ride-by-Wire, diameter 53 mm

Bosch electronic fuel injection system, cylindrical throttle bodies with Ride-by-Wire, diameter 53 mm

Exhaust

Stainless steel muffler with catalytic converter and 2 lambda probes, single stainless steel muffler

Stainless steel muffler with catalytic converter and 2 lambda probes, single stainless steel muffler

Opmerkingen over vermogen/koppel

De aangegeven vermogens-/koppelwaarden worden gemeten met behulp van een motordynamometer volgens de homologatieregeling en komen overeen met de gehomologeerde gegevens, zoals vermeld in het fietsregistratiedocument.

De aangegeven vermogens-/koppelwaarden worden gemeten met behulp van een motordynamometer volgens de homologatieregeling en komen overeen met de gehomologeerde gegevens, zoals vermeld in het fietsregistratiedocument.

Gearbox

6 speed

6 speed

Primary drive

Straight cut gears; Ratio 1.84:1

Straight cut gears; Ratio 1.84:1

Ratio

1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24

1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24

Final drive

Chain; Front sprocket 15; Rear sprocket 43

Chain; Front sprocket 15; Rear sprocket 43

Clutch

Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run

Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run

Frame

Tubular steel Trellis frame

Tubular steel Trellis frame

Front suspension

KYB 48 mm fully adjustable USD fork

KYB 48 mm fully adjustable USD fork

Front wheel

Cast alloy, 3.00" x 19"

Tubeless spoked alloy wheel 3" x 19"

Front tyre

Pirelli Scorpion Trail II 120/70 R19

Pirelli Scorpion Trail II 120/70 R19

Rear suspension

Fully adjustable Sachs monoshock unit. Remote spring preload adjustment. Aluminium double-sided swingarm

Fully adjustable Sachs monoshock unit. Remote spring preload adjustment. Aluminium double-sided swingarm

Rear tyre

Pirelli Scorpion Trail II 170/60 R17

Pirelli Scorpion Trail II 170/60 R17

Wheel travel (front/rear)

170 mm (6.7 in) - 170 mm (6.7 in)

170 mm (6.7 in) - 170 mm (6.7 in)

Front brake

2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc callipers, 4-piston, 2-pad, with ABS as standard equipment

2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc callipers, 4-piston, 2-pad, with ABS as standard equipment

Rear brake

265 mm disc, 2-piston floating calliper, with ABS as standard equipment

265 mm disc, 2-piston floating calliper, with ABS as standard equipment

Instrumentation

LCD

LCD

Kerb weight

229 kg (504.9 lb)

232 kg (511 lb)

Seat height

Not adjustable 840 mm (820 - 860 mm with accessory seats); (33.1 in standard; 32.3 - 33.9 accessory seats)

Not adjustable 840 mm (820 - 860 mm with accessory seats); (33.1 in standard; 32.3 - 33.9 accessory seats)

Wheelbase

1,594 mm (62.76 in)

1,594 mm (62.76 in)

Rake

25,2°

25,2°

Front wheel trail

105.7 mm (4.16 in)

105.7 mm (4.16 in)

Fuel tank capacity

20 l - 5.3 gallon (US)

20 l - 5.3 gallon (US)

Number of seats

Dual seat

Dual seat

Safety Equipments

ABS, Ducati Traction Control (DTC), Riding Mode

ABS, Ducati Traction Control (DTC), Riding Mode

Standard Equipments

Power Mode

Power Mode

Ready for

Warranty

24 months unlimited mileage

24 months unlimited mileage

Maintenance

15,000 km (9,000 mi) / 12 months

15,000 km (9,000 mi) / 12 months

Valve clearance check

30,000 km (18,000mi)

30,000 km (18,000mi)

Standard

Euro 4

Euro 4

CO2 Emissions

124 g/km

124 g/km

Consumption

5,3 l/100 km

5,3 l/100 km

Note:

Only for countries where Euro 4 standard applies.

Only for countries where Euro 4 standard applies.

Engine

Testastretta, L-Twin cylinder, 4 valve per cylinder, Mono Spark, Desmodromic, liquid cooled

Testastretta, L-Twin cylinder, 4 valve per cylinder, Mono Spark, Desmodromic, liquid cooled

Displacement

937 cc

937 cc

Bore X stroke

94 x 67,5 mm

94 x 67,5 mm

Compression ratio

12,6:1

12,6:1

Power

83 kW (113 CV) @ 9.000 giri/min

83 kW (113 CV) @ 9.000 giri/min

Torque

96 Nm (71.0 lb-ft) @ 7,750 rpm

96 Nm (71.0 lb-ft) @ 7,750 rpm

Fuel injection

Bosch electronic fuel injection system, cylindrical throttle bodies with Ride-by-Wire, diameter 53 mm

Bosch electronic fuel injection system, cylindrical throttle bodies with Ride-by-Wire, diameter 53 mm

Exhaust

Stainless steel muffler with catalytic converter and 2 lambda probes, single stainless steel muffler

Stainless steel muffler with catalytic converter and 2 lambda probes, single stainless steel muffler

Opmerkingen over vermogen/koppel

De aangegeven vermogens-/koppelwaarden worden gemeten met behulp van een motordynamometer volgens de homologatieregeling en komen overeen met de gehomologeerde gegevens, zoals vermeld in het fietsregistratiedocument.

De aangegeven vermogens-/koppelwaarden worden gemeten met behulp van een motordynamometer volgens de homologatieregeling en komen overeen met de gehomologeerde gegevens, zoals vermeld in het fietsregistratiedocument.

Gearbox

6 speed

6 speed

Primary drive

Straight cut gears; Ratio 1.84:1

Straight cut gears; Ratio 1.84:1

Ratio

1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24

1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24

Final drive

Chain; Front sprocket 15; Rear sprocket 43

Chain; Front sprocket 15; Rear sprocket 43

Clutch

Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run

Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run

Frame

Tubular steel Trellis frame

Tubular steel Trellis frame

Front suspension

KYB 48 mm fully adjustable USD fork

KYB 48 mm fully adjustable USD fork

Front wheel

Cast alloy, 3.00" x 19"

Tubeless spoked alloy wheel 3" x 19"

Front tyre

Pirelli Scorpion Trail II 120/70 R19

Pirelli Scorpion Trail II 120/70 R19

Rear suspension

Fully adjustable Sachs monoshock unit. Remote spring preload adjustment. Aluminium double-sided swingarm

Fully adjustable Sachs monoshock unit. Remote spring preload adjustment. Aluminium double-sided swingarm

Rear tyre

Pirelli Scorpion Trail II 170/60 R17

Pirelli Scorpion Trail II 170/60 R17

Wheel travel (front/rear)

170 mm (6.7 in) - 170 mm (6.7 in)

170 mm (6.7 in) - 170 mm (6.7 in)

Front brake

2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc callipers, 4-piston, 2-pad, with ABS as standard equipment

2 x 320 mm semi-floating discs, radially mounted Brembo Monobloc callipers, 4-piston, 2-pad, with ABS as standard equipment

Rear brake

265 mm disc, 2-piston floating calliper, with ABS as standard equipment

265 mm disc, 2-piston floating calliper, with ABS as standard equipment

Instrumentation

LCD

LCD

Kerb weight

229 kg (504.9 lb)

232 kg (511 lb)

Seat height

Not adjustable 840 mm (820 - 860 mm with accessory seats); (33.1 in standard; 32.3 - 33.9 accessory seats)

Not adjustable 840 mm (820 - 860 mm with accessory seats); (33.1 in standard; 32.3 - 33.9 accessory seats)

Wheelbase

1,594 mm (62.76 in)

1,594 mm (62.76 in)

Rake

25,2°

25,2°

Front wheel trail

105.7 mm (4.16 in)

105.7 mm (4.16 in)

Fuel tank capacity

20 l - 5.3 gallon (US)

20 l - 5.3 gallon (US)

Number of seats

Dual seat

Dual seat

Safety Equipments

ABS, Ducati Traction Control (DTC), Riding Mode

ABS, Ducati Traction Control (DTC), Riding Mode

Standard Equipments

Power Mode

Power Mode

Ready for

Warranty

24 months unlimited mileage

24 months unlimited mileage

Maintenance

15,000 km (9,000 mi) / 12 months

15,000 km (9,000 mi) / 12 months

Valve clearance check

30,000 km (18,000mi)

30,000 km (18,000mi)

Standard

Euro 4

Euro 4

CO2 Emissions

124 g/km

124 g/km

Consumption

5,3 l/100 km

5,3 l/100 km

Note:

Only for countries where Euro 4 standard applies.

Only for countries where Euro 4 standard applies.
